93 Erase all datalogger contents
94 Datalogger storage period
95 Time setting: minute
96 Time setting: hour
97 Date setting: day of month
98 Date setting: month
99 Date setting: year

USB and Timer Settings

There are three function keys on the display module to implement functions such as USB OTG, timer settings for the
output source priority and timer settings for the battery charger source priority.
USB Functionality
Insert a USB OTG storage device (disk) or a USB disk with a USB OTG microUSB adaptor (Micro-B male to USB Type A
www.phocos.com
No reset (Default)
10 days (Default)
Reset
The Any-Grid unit can store
measurement data with the
following frequency:
3 days: 20 entries per hour
5 days: 12 entries per hour
10 days: 6 entries per hour
20 days: 3 entries per hour
30 days: 2 entries per hour
60 days: 1 entry per hour
Once the memory is full, entries are
over-written.
Available values: 3, 5, 10, 20, 30 and
60 days.
Irrespective of this setting the unit
stores the last 100 error / warning
event codes.
Allows setting the current time in
minutes.
Available values: 00 ~ 59 minutes.
Allows setting the current time in
hours (24h notation).
Available values: 00 ~ 23 hours.
Allows setting the current day of
the month.
Available values: day 01 ~ 31.
Allows setting the current month.
Available values: month 01 ~ 12.
Allows setting the current year (last
two digits: ex. 2019 = 19).
Available values: year 17 ~ 99.
