1.2 Parts Designation

20VAC Motor (CM-080MA)
240VAC Motor (CM-070)
Power Switch
20VAC (KM-07)
240VAC (960-SW)
Keypad (MAX-4)
Automatic Angler
Wing Nut (EGN-)
Cutter Head (KM-06)
Eccentric Shaft
(CM-04)
Cutter Nut (CM-09MA)
Top Jaw (CM-056MA)
Tip Gauge (CM-054MA)
Cutter (Wide Selection
Available)
Bottom Jaw
(CM-055MA)
Shoulder Gauge (CMB-FG)
Emergency Stop Button
(MAX-50)
Pivot Arm (CM-024X)
CodeMax
®
7
