Next, indicate the depth of the first cut. Our example requires a depth of .290. Press "2",
"9", "0", then press ENTER. You will see the following display:
Space 0.231 In
Depth 0.290^ In
Press start to make the cut. Notice that the CodeMax
cutter continues to spin. This allows you to widen the cut, if necessary, by using the space
commands. Press HOME (7) to ready the machine for the next cut.
Review Of Micrometer Key Cutting Procedures
Let's quickly review the basic steps required:
) Press "8" (>).
2) Set spacing numbers from shoulder to first cut, then press ENTER.
) Press start to activate spacing stepper motor.
4) Press "2" (up arrow).
5) Enter depth numbers.
6) Press start for the CodeMax
7) Repeat steps , 2, and  if the cut has to be widened. If the cut does not have to be
widened, press Home (7) to return to the home position.
®
to make the cut.
®
CodeMax
®
stays in the cut position and the
4
