4.3 Micrometer Key Cutting

From the main screen press DSD#. The display shows:
Enter DSD Number
[ ]
Press "0" to signify that you wish to use the micrometer function of the CodeMax . Press
®
ENTER and the display changes to:
Micrometer Key
Cutting Function
The display then changes to:
Enter Jaw Type
[ ]
Press A, B, or C to signify which jaw will be used. For our example, press A. The display
changes to:
Choose: A for In
B for mm
Press A or B to indicate the use of inches or millimeters for space and depth measurements.
For this example, press A for inches. The CodeMax advances to the main micrometer
®
screen and the display shows:
Space 0.000 In
Depth 0.000 In
