HPC CodeMax Manual page 17

Jaw C – Medeco
Keys (Not Required For Biaxial Keys)
Fig. 3a.
An optional cutter (CW-02) and Jaw C (MJ-) are required to cut commercial level
Medeco keys. Both parts are readily available from your HPC distributor. Biaxial keys
®
only require the CW-02 cutter, not MJ-.
The optional Jaw C is a specially milled CodeMax
standard Medeco
the Medeco commercial key grooves. The proper and firm grip provided by Jaw C is
®
necessary due to the extremely deep cuts used on Medeco
Medeco's KeyMark
Gauge the key from the shoulder, making sure the key grooving and special jaw milling are
nested together (see Fig. B).
6
Jaw (MJ-1) Optional Equipment Required For Cutting Medeco
®
Shoulder Gauge
Fig. 3B. properly seated key in jaw C.
keys (see Fig. A). Vise Jaw C is milled to fit and firmly nest into
®
Jaw are available from Medeco
®
jaw. It is required for holding the
®
keys. Instructions for using
®
.
®
CodeMax
®
®
