OPC / OPD / OPE

Commissioning

6 Commissioning
6.1

Connecting the Stationary Read Device

The reader can be controlled via the Vision Configurator software. You have the
ability to make adjustments on the stationary reader directly using the Vision
Configurator software.
Aligning the Stationary Reader
Use the image display in the Vision Configurator software to optimally align the
reader.
1. Power the reader via the 24 VDC + IO socket on the device.
2. Align the device such that the contrast between the code and the background
in the image display is as sharp as possible.
code to be read.
24
This sets the ideal reading distance between the stationary reader and the
