OPC / OPD / OPE
Vision Configurator Software
Format
Image format
Image fine position
Transfer
Image transfer active
Transfer images
Buffer
Buffer images
Overwrite buffer
System Tab, Counter Values Menu Item
Figure 7.10
Selects the image size
752x480 (full screen)
752x240
752x160
752x120
Selecting a smaller field of view can increase the reading
speed.
Moves the field of view up or down (line by line)
The field of view can be moved only if you select a field of
view instead of the full screen under Image format.
Image transfer from the sensor to Vision Configurator
Determines which images are to be transferred to Vision
Configurator
All images: All images
Error images: Images from failed reads
Good images: Images from successful reads
System tab, Counter Values menu item
Specifies which images are to be saved.
The memory holds approx. ten images.
All images: All images
Error images: Images from failed reads
Good images: Images from successful
reads
If this is enabled, the image memory is
continuously overwritten with new images.
In other words, if this is enabled, the image
memory contains the last ten images that
correspond to the settings configured
under Buffer images. If it is disabled, the
image memory contains the first ten
images that correspond to the settings
configured under Buffer images.
