Product Description

4 Product Description
4.1

Use and Application

The optical print inspector is available in three versions and reads both 1-D and 2-
D codes. For high speed, great depth of focus, long barcodes, or detection tasks;
with the optical print inspector you always have the right vision sensor at hand.
Use the innovative image processing technology from Pepperl+Fuchs for your
application.
You can configure the stationary readers quickly and easily over a standard
Ethernet interface, using the software provided. The reader has an integrated fault
pattern memory.
Highlights:
8
Reads 1-D and 2-D codes at extremely high speeds of up to 10 m/s at
30 readings/s
Detects long barcodes of up to 200 mm long using multiple image capture
Reads up to four different codes at the same time
Logo comparison
Position of the reading field can be adjusted flexibly via rotary encoder input
(OPC and OPD)
Captures codes and logos at different distances and of different sizes with
one setting
Side lighting for reliable reading with highly reflective surfaces
