VIM3*-IO-* Vibration Sensors
Commissioning with IO-Link on a Control Panel (Online Parameterization)
5
Commissioning with IO-Link on a Control Panel
(Online Parameterization)
Note
The device description file (IODD) required for integration in an IO-Link system and for
parameterization and diagnosis is available online. Visit www.pepperl-fuchs.com and navigate
to the relevant product page for the VIM3*-IO-* vibration sensor.
To activate the vibration sensor via IO-Link using a control system, proceed as follows:
1.
Check the connection between the vibration sensor and the IO-Link master.
2.
Set the status to "IO-Link" on the corresponding port on the IO-Link master to which the
vibration sensor is connected.
Once communication has been successfully established, parameterize the vibration sensor
with the higher-level application either by using an IO-Link configuration tool or retrieving
diagnostic information. The device sends the determined data as process data.
14
