Text Programming - Pyronix ENFORCER Series Programming Manual

The Internal Tag Reader (EUR-107)
The Internal tag reader can be used for setting/unsetting, entry control or access control. Refer
to the installation manual for all connections.
The External Tag Reader (EUR-108)
The Internal Tag Reader can be used for setting/unsetting, entry control or access control. Refer
to the installation manual for all connections.

2.5 Text Programming

For punctuation marks, press the  key.
In addition, the keys are used as follows:
 = make the character into a capital
 = move cursor left
= clears cursor / adds a space
 = moves cursor right
Enforcer: Programming Manual
To set/unset the system using the External Tag Reader,
present a pre-programmed tag to the centre of the prox.
The prox will display the system status: Green = Unset.
Red = Set. Present the tag again within 10 seconds to set
and unset the system.
NOTE: The system will set depending on the type of exit
mode programmed (Final door, Timed or Push to set)
Text may be programmed for input names, for the 'sign-on'
message, and to identify the Level/Area being Set/Unset. Each key is
allocated alpha-numeric or punctuation marks characters as shown
below:
The Enforcer incorporates predictive text, so the system will predict
which word is being spelt. For example, if 'B' is entered, followed by
'e' then 'd', Bedroom will be displayed. To accept, press . If the
word that is required doesn't appear on the LCD display, type in the
next letter and so forth until complete.
To type a word, press the relevant key the appropriate number of
times – e.g. for the letter 'k' press  twice, or for the letter 's'
press  four times.
Page: 5
Tag Area (Where a valid tag must
be presented to set/unset)
Alert LED
Alarm LED
Tamper LED
Fault LED
Unset LED
