Type
0021 Exit Starts Any
0022 Final Set Any
0023 Strobe Set Fail
0025 Keyswitch unset
0026 Set with Omit
0028 Power Fault
0029 Confirmed Intruder Any
0030 Confirmed Hold Up Any
0031 Entry
0032 Exit
0033 Entry/Exit
0034 Lights
0035 Follow Input
0037 Restore 1
0038 Restore 2
0039 PIR Latch 1
0040 PIR Latch 2
0041 Mains Good
0042 Detr Indn Enable
0043 Follow Test
0044 Off During Test
0048 Detr Walk Test
Detector Masked
0049
(Not applicable on grade 2
systems)
0050 Follow 24 Hour
0051 Comm Fault
0052 Mains Fail
0053 Battery Faults
0054 Low Volts
Global Fault 1
0055
(Faults: Modem, Battery,
Enforcer: Programming Manual
Active
LAST partition
When exit time starts to set
FIRST area
When FIRST area is set
Works similar to output 016, but also fires if the set fail timer
expires.
This output turns on for 5 seconds when the system is disarmed
via a keyswitch input (pulsed or latched)
Activates when inputs are omitted on setting
Active during low volts and battery faults
entry after fault cleared.
When more than one intruder
alarm activates
When more than one
confirmed hold up activates
Live during entry time
Live during exit time
Live during any entry or exit time
When exit or entry timer starts
When input triggers
At code entry to set
At code entry to set
Re-triggers whenever an additional area is set
When set (and in Walk Test)
This is the inverse polarity to PIR Latch 1
Output showing the mains is healthy
This output activates during walk test and also when a code is
entered to view indications – staying activated for the time for
which the indications are viewed.
New output for alternative bell test by activating SAB
New output for alternative bell test by activating SAB
This output is active during walk test, and will only deactivate
when all detectors have been tested.
If any detector goes into
'mask' condition the output will
trigger
If any input programmed as
"Day alarm" activates
When a commuinicator Fault
has signalled
After pre-set time without
mains power
When battery disconnected or
load fail detected
At fault
Activates if fault occurs only
when system is armed
Page: 38
Restore
partition
At code entry to unset LAST
area
At code entry to unset LAST
area
. Restores at code
*
At next code entry
At next code entry
20 seconds after set/unset
procedure completed
Dependent upon programming
After 3 seconds
When unset
At alarm, or when unset
When masking fault clears.
When input restored
When fault clears
On restoration of mains
At next valid code entry
When fault clears
When all faults cleared
