3.0 The PowerSeries Pro Security System

The PowerSeries Pro has been designed to provide the greatest possible flexibility and convenience.
Read this manual carefully and have the installer provide instructions on how to operate the system and
which features have been implemented. All users of this system should be equally instructed in its use.
Fill out the "System Information" section with zone information and access codes and store this manual in
a safe place for future reference.
NOTE: The PowerSeries Pro security system includes specific false alarm reduction features and is clas-
sified in accordance with ANSI/ SIA CP-01-2014 Control Panel Standard - Features for False Alarm
Reduction. Please consult the installer for further information regarding false alarm reduction features
built into the system as all are not covered in this manual.

3.1 General System Operation

This security system is made up of a PowerSeries Pro control panel, one or more keypads and various
sensors and detectors. The metal cabinet contains the system electronics and standby battery. The
keypad is used to send commands to the system and to display the current system status. The keypad(s)
are mounted in a convenient location inside the protected premises close to the entry/exit door(s). The
security system has several zones of area protection, each connected to one or more sensors (motion
detectors, glassbreak detectors, door contacts, etc.).
NOTE: Only the installer or service professional shall have access to the control panel.

3.2 Carbon Monoxide Detection

This equipment is capable of monitoring carbon monoxide detectors and providing a warning if carbon
monoxide is detected. Please read the Escape Planning guidelines in this manual and instructions that
are available with the carbon monoxide detector.
NOTE: Must be enabled and configured by installer.
NOTE: The equipment should be installed in accordance with NFPA 720.

3.3 Fire Detection

This equipment is capable of monitoring fire detection devices such as smoke detectors and providing a
warning if a fire condition is detected. Good fire detection depends on having adequate number of detect-
ors placed in appropriate locations. This equipment should be installed in accordance with NFPA 72
(N.F.P.A., Batterymarch Park, Quincey MA 02269). Carefully review the Escape Planning guidelines in
this manual.
NOTE: Must be enabled and configured by installer.

3.4 Testing the System

Tests all system keypad LEDs, keypad sounders, bells and/or sirens. To ensure the system continues to
function as intended, test your system weekly.
For UL HOME HEALTH CARE listed applications the system shall also be tested weekly
IMPORTANT:
without AC power. To remove AC from the control unit, remove the screw from the restraining tab of the
plug in adapter and remove the adapter from AC outlet. After completing the test of the unit using only the
battery backup source, reconnect the plug in adapter and attach the screw through the restraining tab so
that the adapter is securely attached to the outlet.
Should the system fail to function properly contact the installation company.
IMPORTANT:
All smoke detectors must be tested by the smoke detector installer once per year.
IMPORTANT:
To Perform a Keypad and Siren Test
1. Press [*][6] and enter the [Master Code] to access User Functions.
2. Press [04] or use the scroll keys to navigate to System Test and
press [*]. All keypad sounders, bells/sirens and keypad LEDs activ-
ate for two seconds.
3. Press [#] to return to the Ready state.
- -
7
LCD Display
Press (*) for <>
User Functions
Press (*) for <>
System Test
