Chapter
11
Trouble
Trouble
Level 1
Condition
Communications 11
Not Networked
12
AUX Trouble
13
Description
The system has detected a com-
munication trouble. Call for service.
The system has detected a network
trouble condition with one or more
modules on the system.
If the trouble does not restore within
20 minutes, call for service.
The system has detected a trouble
on the AUX terminal.
-
-
38
Trouble
Notification
Trouble Types
Level 2
TLM
01
n/a
FTC
02
Receiver
1-4
SIM Lock
03
n/a
Cellular
04
n/a
Ethernet
05
n/a
Receiver
06
Receiver
1-4
Supervision
07
Receiver
Receiver
1-4
Alt Comm Fault
09
n/a
Alt Comm FTC
10
Receiver
1-4
Zone
01
Zone label
001-128
Keypad
02
Keypad 1-
16
Siren
03
Siren 1-16
Repeater
04
Repeater
1-8
User
05
Users
01-1000
Zone
01
Zone
Power
05
Power Sup-
Supply
ply 1-8
High-current
06
Module 1-4
O/P
System Area
07
n/a
8 I/O Module
10
Module 1-
15
Bus Repeater
11
Repeater
1-8
3A Power Sup-
12
Aux 1
ply Aux 1
Trouble
3A Power Sup-
13
Aux 2
ply Aux 2
Trouble
Level 3
