Page 1: Table Of Contents
Fire Initiating Devices and Notification Appliances Technical Manual 408 Notification Appliances Section Technical Bulletin Issue Date 1095 PS12/24ADA Series Signaling Strobe and Sounder Introduction Page General Description Installation Procedures General Information Mounting Wiring Installation Guidelines Limitations © 1995 Johnson Controls, Inc. Code No. LIT-408240... - Page 2 2 Notification Appliances—PS12/24ADA Series Signaling Strobe and Sounder...
-
Page 3: Introduction
PS12/24ADA series signaling strobes and piezo electronic sounders. These strobes and sounder/strobes are manufactured by System Sensor for use with Johnson Controls systems. The strobes are UL 1971 Listed for signaling devices for the hearing impaired. Those models that produce 75 candela (cd) meet the Americans with Disabilities Act (ADA) light output requirements of 75 cd on axis. -
Page 4: General Description
General CAUTION: Equipment hazard. Do not use in potentially Description explosive atmospheres. Do not leave unused wires exposed. The piezo electronic sounder and signaling strobe are intended to be connected to the alarm indicating circuit of a UL Listed fire alarm control panel. - Page 5 Table 1: PS12/24ADA Series Specifications Mechanical Input Terminals 12 to 18 AWG (3.31 to 0.82 mm Dimensions 4 in. W x 7 in. L (101.6 mm W x 177.8 mm L) Front of Backbox to Front of Unit 3 in. (76.2 mm) 1/2 in.
- Page 6 Light Distribution UL 1971 requires a polar light distribution pattern to enhance the likelihood of alerting hearing impaired individuals throughout an area. Figure 1 illustrates the way the standard measures light intensity, both horizontally and vertically. Wall Mount Vertical Light Distribution P erce n t of R ated Zero Axis...
- Page 7 Power All models can be powered using Full-Wave Rectified (FWR), unfiltered Requirements (unregulated) power supplies. However, if the power supply is unregulated, the notification appliance must be compatibility listed for use with the fire alarm system. If the power supplied is from a regulated power supply, no compatibility listing is required.
- Page 8 Table 3: Operating Current from Full-Wave Rectified, Unfiltered, Unregulated Supply Model Operating Supply Average Peak Current Peak Inrush Voltage Voltage Operating (mA) Current Current Range Current 20 VRMS/ (mA) (mA in Excess (mA RMS) 30 VRMS 10.5 VRMS/ of Peak) 17 VRMS PS24110ADA 24 volt...
-
Page 9: Installation Procedures
Installation Procedures This section contains installation information for PS12/24ADA series General strobes and sounder/strobes. Mounting instructions and wiring Information information are provided. Installation procedures must conform to all applicable codes and the requirements of the authority having jurisdiction. Strobe Placement For strobe placement, read and be familiar with: NFPA 72-National Fire Alarm Code Both slotted-head and Phillips-head screws are supplied with the... - Page 10 Mounting Figures Table 4: Screw Types for Figures Letter Screw Type 6-32 x 1-1/2 in. Phillips-head, Oval No. 8-32 x 5/8 in. Slotted-head, Pan No. 6-32 x 5/8 in. Slotted-head, Pan No. 8 Phillips-head Sheet Metal, Oval S ingle G ang Backb ox p s 1 2m ta Figure 2: Surface Mount to Single Gang Box 1.
- Page 11 S ingle G an g B ackbox P S -FP S emi-flu sh P late p s 1 2m n tc Figure 3: Semi-flush Mount to Single Gang Box 1. Complete the field wiring as described in the Wiring Installation Guidelines section of this technical bulletin (Figure 7).
- Page 12 4 in ch S quar e B ackbox P S -FP S em i-flush Moun ting Plate p s 1 2 m ntb Figure 4: Semi-flush Mount to 4 inch Square Backbox 1. Screw semi-flush plate to 4 inch square backbox with Type B screws. 2.
- Page 13 4 inch S quare B ack box P laster R ing PS -FP S emi-flu sh M ou nting P late p s 1 2m td Figure 5: Semi-flush Mount with Plaster Ring 1. Screw semi-flush plate to box with Type C screws. 2.
-
Page 14: Wiring Installation Guidelines
Note: Do not loop the Notification Appliance Circuit (NAC) wires under Wiring the terminal screw. Wires must be broken at the device terminal Installation connection in order to maintain electrical supervision. Guidelines T his N ot Th is w irg uide Figure 6: Electrical Connections Wiring Diagram N AC... -
Page 15: Limitations
Johnson Controls recommends that the signaling strobe and sounder be used in combination to minimize risk. The signaling strobe cannot operate from coded power supplies. - Page 16 Notes Controls Group FAN 408 507 E. Michigan Street Fire Initiating Devices and Notification Appliances Technical Manual P.O. Box 423 Printed in U.S.A. Milwaukee, WI 53201 16 Notification Appliances—PS12/24ADA Series Signaling Strobe and Sounder...
