  • Page 1 PENN Connected PC10 Install and Commissioning Guide PC10, RMZ-1214-E10, RMZ1214E11-NT1, RMZ1214E11-NT3, RMZ1214E20, RMZ1214E61-DS1 Johnson Controls LIT-12013314 www.penncontrols.com 2020-08-10...
  • Page 2 PENN Connected PC10 Install and Commissioning Guide...
  • Page 3: Table Of Contents

    Installing and commissioning the door sensors................16 Signing off..............................17 Troubleshooting............................17 Frequently asked questions........................17 Related documentation..........................19 Product warranty............................19 Software terms............................. 19 Single point of contact..........................19 Contact information............................. 19 PENN Connected PC10 Install and Commissioning Guide...
  • Page 4 PENN Connected PC10 Install and Commissioning Guide...
  • Page 5: Introduction

    Introduction The PENN Connected PC10 Remote Wireless Monitoring System provides automated temperature monitoring solutions for the food retail industry. Examples of equipment for monitoring The following list provides examples of typical refrigeration equipment that the PC10 system can monitor: • Wall chillers and freezers •...
  • Page 6: Pre-Installation Survey

    Pre-installation survey Before you install and commission the PENN Connected PC10, perform a pre-installation survey on the premises. The pre-installation survey can help to determine the optimal placement of hardware in a premises. Use the pre-installation survey to assess the following site conditions:...
  • Page 7: Probe And Sensor Placement

    Example of a site layout See the following figure and table for an example of a site layout with typical locations for hardware installations. Figure 1: Site layout with hardware locations PENN Connected PC10 Install and Commissioning Guide...
  • Page 8: Overview Of The Gateway

    • Do not install the gateway in a refrigerated space; install it in an adjacent ambient area instead. See the following figures for examples of installation locations for gateways: Figure 2: Typical central point in a premises PENN Connected PC10 Install and Commissioning Guide...
  • Page 9: Installing And Commissioning The Gateway

    - Blue network light blinks rapidly to indicate connection to the ZigBee network - Red data light blinks to indicate the transmission of data through the GSM network - Green server light remains steady to indicate connection to the internet Figure 4: Gateway light sequence PENN Connected PC10 Install and Commissioning Guide...
  • Page 10: Overview Of Repeaters

    Each repeater can connect to 15 sensors. The repeaters do not require commissioning. See the following figure for an example of an installation location for repeaters: Figure 5: A repeater in position on top of a cabinet PENN Connected PC10 Install and Commissioning Guide...
  • Page 11: Installing The Repeaters

    • The sensors can record temperatures from -40° to 95° in refrigerated or hot hold cabinets. Replace the negative temperature coefficient (NTC) external probe to suit the application. See the following figures for examples of typical sensor placement. Figure 6: Typical view of well and wall cabinets PENN Connected PC10 Install and Commissioning Guide...
  • Page 12 Figure 7: Internal sensor fitted in a wall cabinet Figure 8: Internal sensor fitted in a coffin freezer PENN Connected PC10 Install and Commissioning Guide...
  • Page 13 Figure 9: Close up of an internal sensor fitted in a coffin freezer Figure 10: External sensor in an upright chiller PENN Connected PC10 Install and Commissioning Guide...
  • Page 14 Figure 11: External sensor probe inside a cabinet Figure 12: External sensor probe in a freezer room PENN Connected PC10 Install and Commissioning Guide...
  • Page 15: Installing And Commissioning The Temperature Sensors

    Attach these stickers to the refrigeration units to track and trace the door sensors. See the following figure for an example of a door magnet and reed switch. PENN Connected PC10 Install and Commissioning Guide...
  • Page 16: Installing And Commissioning The Door Sensors

    Attach the magnet and reed strip to the frame of the chiller or freezer room door with a maximum gap of 20 mm. Attach a sticker to a visible location on the refrigeration unit. PENN Connected PC10 Install and Commissioning Guide...
  • Page 17: Signing Off

    Do I need more than one gateway to monitor a cold storage warehouse? You need only one gateway if you use the load and distance rules to plan the sensor and repeater layout. What is the purpose of the green plug on the gateway? PENN Connected PC10 Install and Commissioning Guide...
  • Page 18 How often does the cloud platform receive the sensor readings? The cloud platform receives the sensor readings every 15 minutes in 5 minute segments. To change the frequency of these intervals, contact PENN Connected support. PENN Connected PC10 Install and Commissioning Guide...
  • Page 19: Related Documentation

    NO. 32 CHANGJIJANG RD NEW DISTRICT 45143 ESSEN MILWAUKEE WI 53202 WUXI JIANGSU PROVINCE 214028 GERMANY CHINA For more contact information, refer to www.johnsoncontrols.com/locations. Contact information Contact your local branch office: www.johnsoncontrols.com/locations Contact Johnson Controls: www.johnsoncontrols.com/contact-us PENN Connected PC10 Install and Commissioning Guide...
  • Page 20 © 2020 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision and are subject to change without notice.
