Layout - inVENTer iV12-Smart Corner Installation And Operating Instructions Manual

2.1

layout

12
11
10
iV12-Smart with weather protection hood
Fig. 1: Overview of iV12-Smart ventilation unit (weather protection hood / corner)
1 Interior plaster
2 Inner cover base plate
3 Inner cover holding plate
4 Inner cover
Wall sleeve
Fig. 2: Wall sleeve
1 Controller cable recess
2 Fixing element
inVENTer ® iV12-Smart ® /iV12-Smart
2
1
8
5
6
7
9
5 Wall sleeve
6 Fan with felt strip
7 Thermal accumulator
8 Weather protection hood
base plate (l.h.) /
corner lat tube (r.h.)
® Corner ventilation system
12
3
4
11
10
iV12-Smart with corner connection
1
2
•
Installation and operating instructions
sysTem oVerVieW
1
7
6
8
9
9 Weather protection hood cover
(l.h.) / embrasure lattice (r.h.)
10 Exterior render
11 Insulation
12 Masonry
2
3
4
5
7
