inner cover
inner cover V-220x200
Characteristics
Width / height / depth - open (closed)
Filter channel diameter
Fixing hole spacing
Weight
Colour
inner cover r-D290
Characteristics
Diameter / depth - open (closed)
Filter channel diameter
Weight
Colour
inVENTer
®
iV12-Smart
®
/iV12-Smart
224 mm / 204 mm / 70 mm (50 mm)
190 mm
203 mm / 183 mm
0.850 kg
White - RAL 9010
290 mm / 70 mm (50 mm)
240 mm
0.600 kg
White - RAL 9010
®
Corner ventilation system
sPeCifiCaTion
Value
Value
•
Installation and operating instructions
57
