Quick Menu 012 Par. 326 Output relay 2
(RELAY 2 FUNCTION)
Value:
29 optional settings
Function:
This output activates relay switch 02. This low voltage
relay is generally programmed to provide a remote
run indication. There are 29 optional settings.
Running makes this relay close when the drive
is running. This is the default setting.
Description of choice:
Select relay 2 function.
Quick Menu 013 Par. 415 Units relating
to closed loop
(REF. / FDBK. UNIT)
Value:
No unit
%
rpm
ppm
pulse/s
l/s
l/min
l/h
kg/s
kg/min
kg/h
3
m
/s
3
m
/min
3
m
/h
m/s
mbar
bar
Pa
kPa
mVS
kW
C
GPM
gal/s
gal/min
gal/h
lb/s
lb/min
lb/h
CFM
3
ft
/s
3
ft
/min
MG.60.I3.02 - VLT is a registered Danfoss trademark
Cascade Controller Option
3
ft
/h
ft/s
in wg
ft wg
RUNNING
PSI
2
lb/in
HP
F
Function:
This unit will be used for the reading in the Display
mode and as a unit for Minimum / Maximum
Feedback, Minimum / Maximum Reference, Warning
Feedback High/Low and for the H1, H0 and the
calculated Hmx parameter settings/readings.
Description of choice:
Select the unit for the reference/feedback signal.
Quick Menu 014 Par. 413 Minimum feedback
(MIN. FEEDBACK)
[0]
Value:
[1]
-999,999.999 - FB
[2]
[3]
Function:
[4]
Parameters 413, Minimum feedback and 414,
[5]
Maximum feedback are used to scale the feedback
[6]
signal ensuring that it shows the feedback signal
[7]
proportionally to the signal at the input.
[8]
[9]
Description of choice:
[10]
Set the value to be shown on the display when the
[11]
feedback signal is at its minimum value.
[12]
[13]
[14]
Quick Menu 015 Par. 414 Maximum feedback
[15]
(MAX. FEEDBACK)
[16]
Value:
[17]
FB
- 999,999.999
[18]
MIN
[19]
Function:
[20]
Parameters 413, Minimum feedback and 414,
[21]
Maximum feedback are used to scale the feedback
[22]
signal ensuring that it shows the feedback signal
[23]
proportionally to the signal at the input.
[24]
[25]
Description of choice:
[26]
Set the value to be shown on the display when the
[27]
feedback signal is at its maximum value.
[28]
[29]
[30]
[31]
MAX
100.000
[32]
[33]
[34]
[35]
[36]
[37]
[38]
[39]
0.000
33
