Contents
MG.60.I3.02 - VLT is a registered Danfoss trademark
Safety regulations ...................................................................................................
Warning against unintended start ...........................................................................
............................................................................................
Cascade Control Operation ...................................................................................
Standard Cascade Control Mode ..........................................................................
Master/Slave Cascade Control Mode ....................................................................
Installing the cascade controller option card ..........................................................
Standard cascade control wiring diagram .............................................................. 17
Optional Hand/Off/Auto Switch .............................................................................. 18
Master drive in master/slave control wiring diagram .............................................. 19
Slave drive in master/slave control wiring diagram ................................................. 20
Introduction ............................................................................................................ 21
Changed systemstop functions .............................................................................. 22
Serial communications(parameter 500) .................................................................. 22
................................................................................................... 23
How to use the LCP for programming ................................................................... 23
Control keys for parameter setup .......................................................................... 23
Indicator lamps ...................................................................................................... 23
Drive Control .......................................................................................................... 23
Display modes ....................................................................................................... 24
Changing data ....................................................................................................... 25
Parameter setting procedure .................................................................................. 26
Example of how to change parameter data ........................................................... 26
Manual initialization ................................................................................................ 26
Introduction ............................................................................................................ 28
Quick Menu Summary ........................................................................................... 29
Language ............................................................................................................... 29
Motor nameplate data ............................................................................................ 30
Relay outputs ......................................................................................................... 32
Alternate programming ........................................................................................... 36
Introduction ............................................................................................................ 38
Initial Setup ............................................................................................................ 39
Alternate programming ........................................................................................... 45
Introduction ............................................................................................................ 46
Initial Setup ............................................................................................................ 46
Cascade Controller Option
................................................................................
.....................................................
............................................................................ 21
........................................... 28
..................................................... 38
................................................... 46
3
4
4
6
6
7
8
9
9
1
