Setup and installation
Laser rack and PC
The laser rack and the PC should be located next to or directly above one another if possible in order for the
modules to be connected to one another with the cables provided.
When installing in a control cabinet or rack, ensure there is sufficient ventilation. Both the laser rack and the
PC require a sufficient supply of air. The air should be sucked in from the front and blown out at the rear.
When installing the laser rack, also ensure the minimum radius of curvature of the fiber optic cable (black
tube) is not exceeded on the rear side.
Galvanometer scanner controller card
The enclosed galvanometer scanner controller card needs to be installed in a computer. The installation
guide is enclosed in the accessory.
Software installation
The software will be installed by starting the SETUP.exe from the software-CD. Please follow the steps on
the screen. The correct configurations files must be installed after the software setup is finished.
The installation guide is enclosed in the accessory.
7.5

Electrical installation

Following the mechanical installation of the marking head, laser rack and PC, the components must be
connected to one another electrically. (The laser rack and marking head are already connected to one
another on delivery.) The peripherals (power supply, external control and safety signals, etc.) are then
connected via the laser rack and PC interfaces.
All connectors are clearly identified in order to facilitate the electrical installation. The connector marked X43
belongs to the socket with the same denotation.
The connector denotations are also coded. The last digit of the connector denotation identifies the respective
hardware components.
Therefore:
X ... 1 Laser rack
X ... 2 Marking head
X ... 3 PC interfaces
