Operation
8.4

Power On/Off

1. Press the master switch ❶ on the laser rack.
2. The switch is illuminated in green and the two status lamps on the marking head also illuminate in green
(shutter closed).
3. Put the key in the key switch ❼ (vertically) and turn 90° to the right.
4. Press the ❻ "Error reset" button to reset the system to its normal state.
5. System ready ❷, Shutter ❸ and the two status lamps (red) on the marking head should now be
illuminated. The laser is now ready to start marking.
6. Start the PC. (The mains switch is located on the front behind the right hand cover. When operating the
system for the first time it may be necessary to check the master switch on the reverse side of the PC. In
its normal state this can remain in the "On" position.)
7. Now start the marking software on the PC.
If an error occurs, the ❻ "Error Reset" button illuminates. Pressing this button acknowledges the error and
the system is then ready to continue operating.
We recommending using only the key switch ❼ to pause the laser. To completely turn off the laser, the main
switch ❶ must be set to O.
