User Guide
DVS-21

9.19 Remote - Intercom forwarder

Transmission of Remote - Intercom connections in temporary systems
Flag (NAND) [IN] The program can be turned off by this flag or switching on can be prevented.
Codec audio compression process to be used
Long distance line
Specifications of where incoming and outgoing Long distance line lines are connected.
In the case of Transmission via 2Mbps, Transmission line controlling and Transmission line AF are
identical.
Address, Port Address of the transmission line
Control lines The lines correspond with the

9.20 ZZ connection

ZZ connection refers to a intercom connection between a DVS-21 and a analog third party system. The
connection is made by means of a
Priority
Own/Analog
Input/call station (Setting Own)
Address, Port, Line
Input/call station (Setting Analog)
Address AF, Port
Address 24LI, Port,
Line
Call storage
AllCall number of own
station
Illumination on lead
flag
Special line
Flag (NAND)
Flag (OR)
Flag (OUT) 1/2
Lead flag
02/2018 • V.1.0 • L. Wolle
© 2017 ProCom
Remote - Intercom
4ZZA module.
Handling of priorities (see Section
Selection of the type of call station (ProCom or analog call stations).
Address and port of the module to which the call station is connected and the line
(key) that is used. (4NSA)
Address and port of the module to which the AF line of the call station is
connected. (4NPA)
Address, port and line of the module to which the control line of the call station is
connected. (24LI)
Time for which the key is illuminated (flashing) after missed calls
A ZZ connection can react to an AllCall of the specified number. (also many) The
triggering AllCall program must must be programmed on the same station.
Address, port and line (key) to be illuminated during the playback of a pre-
announcement chime or alarm tone.
Function subject to use of the Lead flag!
The line is switched on if the program is activated. For example, relays can be
switched on or keys can be illuminated.
[IN] The program can be turned off by this flag or switching on can be prevented.)
[IN] [IN] The program can be switched on by this flag. It is possible to take over
AF channels.
[OUT] The flag is switched on if the program is activated. Other programs can be
triggered.
[OUT] The flag allows the upstream switching of a pre-announcement chime or
alarm tone subject to the use of the
lead 2 program.
®
Professional Communication & Service GmbH • Technical changes reserved.
(see Section 9.1)
program.
9.1)
DSS1 module and the Alarm flag in the Alarm
