User Guide
DVS-21

10.7 LB splitter

Program for the transmission of LB telegrams by means of cascaded systems with local connection of a
USE2 module (upgraded Repeater mode)
Should multiple segments be switched sequentially in LB Repeater mode, then the system determines
that the total reaction time is the sum of each individual segment. If the systems are, however, connected
by means of 2Mbit lines, this program enables programs of all stations to be controlled within a very
narrow time frame.
USE2 Local
USE2 Recognition
Long-distance line control

10.8 Call number converter

Program for the transfer of a telephone number to the
as a telegram to Port 3.
Lines 1 - 10 correspond to the digits 1 - 9, 10 = 0, 11-14 = A-D, 15 = # and 16 = *
Output (USE2)
Address of the
Address, Port
module.
Transfer with line The transferral of the telephone number takes place by means of lines.
The transferral of the telephone number takes place by means of special
Transfer as telegram
telegrams.
Number of digits Number of digits that make up the telephone number. (max. 16)
Pause between digits Pause until transmission of the next digit as Line.
Duration of activation The lines are active for this time.
Start delay Pause before the program transfers the first digit as Line.
16 fields for the digits of the telephone number.
Digits
The following are valid: 0 - 9, A - D, #, * and P for Pause!
Flag (NAND) [IN] The program can be turned off by this flag or switching on can be prevented.
Flag (OR) [IN] The program can be switched on by this flag.
[OUT] The flag is switched on if the program is activated. Other programs can be
Flag (OUT) 1/2
triggered.
02/2018 • V.1.0 • L. Wolle
© 2017 ProCom
Address and port of the local USE2 mode
ID of the LB connection
Address and port of the control system
USE2 module. Reception always takes place at Port 3 of the
®
Professional Communication & Service GmbH • Technical changes reserved.
USE2 module. The transfer takes place by Lines or
103/131
