Measurement

Start measuring
starts a reference measurement
Control measuring
starts a comparative measurement
The reference value of the measurement is only stored in the configuration file when saved. The
configuration file must be transferred to the system, in order for the impedance test to operate with this
value.

9 Programs for AF-transfer

9.1 Overview

Explanation of the parent configuration boxes of many AF-programs!
Priority, Audio channel, Audiokompression
There are 255 levels available, with 1 being the highest. Priorities are dealt with on
destination. If a program finds an occupied destination, the priorities of both
Priority
programs are compared. If the priority of the new connection is higher, the existing
connection will be displaced.
In programs with this channel box is the possibility to use a fixed audio channel
Fixed audio channel instead of a dynamic one. It is useful in conjunction with a DSS1 because this
module works with eight predefined channels.
Audio compression method of the codec for the actual connection.
The options are: µLaw (default), ADPCM (7kHz) and aLaw
Please note: Depending on the firmware of the module and the equipped codec
Codec
type, different combinations of audio compression methods are available.
Codec IC (with pins) µLaw and aLaw
Codec IC (SMD)
02/2018 • V.1.0 • L. Wolle
© 2017 ProCom
µLaw, aLaw and ADPCM (7kHz)
®
