9.7 Intercom radio 2

Program to switch on radio stations with differentiation of frequency bands when using the
in the DB-Radio (Tone call) mode
Priority
Own/Analog
Input/call station (Setting Own)
Address, Port, Line
Input/call station (Setting Analog)
Address AF, Port
Address 24LI, Port, Line
Keying line
PTT line
Clear line
Tone call
To differentiate radio coverage, the Railway radio stations recognize three call tones (1520, 1750 and
2135 Hz). The DSS1 module can detect and evaluate these sine frequencies. The Radio AF is therefore
switched permanently in idle mode to the fixed AF channel specified under Audio channel - Radio AF.
No DSS1 (e.g. 24LI)
Section line
Audio channel - Radio AF
DSS1 busy line No.
02/2018 • V.1.0 • L. Wolle
© 2017 ProCom
Handling of priorities
Selects the type of call station (ProCom or analog call stations).
Address and port of the module to which the call station is connected
and the line (key) in use. (4NSA)
Address and port of the module to which the AF line of the call station is
connected. (4NPA)
Address, port and line of the module to which the control line of the call
station is connected. (24LI)
Keying in frequency band.
(Key is illuminated continuously, PTT key flashes)
Line (key) for the PTT key
Switches the AF to the module specified under Radio AF. (AF line of
the radio station)
The fixed AF channel specified under Audio channel - Radio AF is
used. (26/27/28/29)
(see Table Fixed audio channels
When pressing the PTT key, the Line and the Flag (OUT) specified
under Transmit switch are activated.
The connection can be broken via this Line (key).
The module specified by Address, Port, Section line is not a DSS1. The
Tone call evaluation takes place externally.
When a call frequency is detected, the DSS1 module activates the
respective Line.
The lines are permanently assigned to the frequencies. (5=1520Hz,
6=1750Hz, 7=2135Hz)
(see Lines of the Module DSS1)
Fixed audio channels
26 - 29) (depending on port)
The DSS1 module is already active and no evaluation can take place.
(Line 1)
(see Lines of the module DSS1)
Freely programmable if switched on externally.
®
Professional Communication & Service GmbH • Technical changes reserved.
(see Section 9.1)
of the DSS1) module
of the DSS1 module for reception (Audio channel
DSS1 module
