User Guide
DVS-21
Flag (OUT) 1/2
AF Flag (OUT)
Lead flag
Illumination on lead flag
Suppress busy status message

9.13 Public address 2 "PA remote/local"

Program for local control of amplifiers or in remote systems for forwarding to transmission systems
Call station - Amplifier
Call station - Long distance line
Long distance line - Long distance line
Long distance line - Amplifier
Priority
Codec
PA ID
Transmission via 2Mbps
Busy message
Call station selection - xxx
Own/Analog
Acknowledgment
Input/call station (Setting Own)
Address, Port, Line
Input/call station (Setting Analog)
Address AF, Port
Address 24LI, Port, Line
02/2018 • V.1.0 • L. Wolle
© 2017 ProCom
[OUT] The flag is switched on if the program is activated. This enables
further programs to be activated for adaptation to specific requirements.
[OUT] Flag as before. Audio channel transfer possible.
[OUT] The flag enables the pre-announcement chime or alarm tone to be
connected upstream if the
used.
Address, port and line (key) of a call station to indicate the activity of the
alarm lead. The indication is switched on for the playing time of pre-
announcement chime or alarm sound.
Suppressing the busy indication on the call station.
Source and destination are part of a local system
Source (from station to outgoing long-distance line)
Intermediate system (connection of incoming/outgoing long-
distance line)
Destination (from incoming long-distance line on amplifier)
Handling of priorities
Audio compression method with which the codec handles the
actual connection.
The options are: µLaw (default), ADPCM (7kHz) and aLaw
Section 9.1)
ID of the Source-Destination program
AF transmission takes place via a multi-channel digital connection
(Address and port for the control system and AF are identical)
Specifications for transmission of busy message
Selects the type of call station (ProCom or analog call stations).
Type of display of a acknowledgment at the station
Address and port of the module to which the call station is
connected and the line (key) that is used. (4NSA)
Address and port of the module to which the AF line of the call
station is connected. (4NPA)
Address, port and line of the module to which the control line of
the call station is connected. (24LI)
®
Professional Communication & Service GmbH • Technical changes reserved.
DSS1 module a the Alarm lead 2
(see Section 9.1)
program are
(see
88/131
