9.8 Intercom radio monitoring

Program for switching on monitoring option for radio on stations or PA loudspeakers. Only suitable when
used in connection with ProCom stations and their monitoring connection(Ma/b)!
Start function Address, port and line (key) to activate the program. (4IOS, 24LI)
Address and port of the module (usually 4NPA), to which the AF line of the radio station
Radio AF
is connected.
Address and port of the AF module to which the monitoring connection Ma/b is
Monitor address
connected.
To suppress the Tone call frequencies
Tone call Address, port and line of the module for Tone call evaluation (DSS1) or another module
that provides the information (remote control)
Flag (NAND) [IN] The program can be turned off by this flag or switching on can be prevented.
Flag (OR) [IN] The program can be switched on by this flag. It is possible to take over AF channels.
[OUT] The flag is switched on if the program is activated. This enables further programs
Flag (OUT) 1/2
to be activated for adaptation to specific requirements.

9.9 AllCall

The AllCall program functions locally. Only destinations to which a voice connection can be established
from the specific station by means of one of the following programs can be integrated:
Group, PA Public address,
Stations in remote systems can be addressed locally by means of the
the destination system by means of the
option of using the pre-announcement chime or the alarm tone.
Priority Handling of priorities
Audio compression method with which the codec handles the actual connection.
Codec
The options are: µLaw (default), ADPCM (7kHz) and aLaw
AllCall No. ID of the connection
Own/Analog Selects the type of call station (ProCom or analog call stations).
Input/call station (Setting Own)
Address and port of the module to which the call station is connected and the line
Address, Port, Line
(key) that is used. (4NSA)
Input/call station (Setting Analog)
Address and port of the module to which the AF line of the call station is connected.
Address AF, Port
(4NPA)
Address 24LI, Port,
Address, port and line of the module, to which the control line of the call station is
Line connected. (24LI)
