7.13 USE1 (RS232)

Interface module with a serial interface RS232 (Backplane connector). The module will be exclusively
used with custom specific firmware for specific tasks.
Application: communication with other devices or PCs.

Operation mode Exchange interconnection

System connection by means of RS485 and impulse burning device (Custom-made product for opencast
mining).
Attention! Only up to Hardware version 2 (not for new systems)!
Program USE1 intercom only up to DVS Firmware 7.21
Connection starts with audio
channel
Own exchange No.
Impulse burning device when slip rings are used in the cable path
No. of faulty telegrams
Minimum time between burn
pulses
No. of connections

Operation mode RS232 protocol

Communication via serial RS232 interface.
Attention! (not for new systems)!
Program RS232 protocol only up to DVS Firmware 7.26
RS232 generally-used settings for a serial RS232 interface
Programming takes place by means of the RS232 protocol program.
02/2018 • V.1.0 • L. Wolle
© 2017 ProCom
Preferential channel, by which the establishment of a connection is
initiated
Unique system number in system network
Number of faulty telegrams within 8ms until accessory burning Module
attempts to burn the slip rings free.
Minimum interval in seconds between two burn impulses
Number of simultaneous connections
®
