Remote - Allcall - Procom DVS-21 User Manual

User Guide
DVS-21

9.18 Remote - AllCall

AllCall is a simultaneous, single-sided speech connection to multiple stations and loudspeaker lines.
The Remote - AllCall program can replace the
pre-announcement chime/alarm tone.
All destinations to which a voice connection with the specific station exists via one of the following
programs, can be integrated.
In addition, an outgoing connection can be programmed via a long-distance line. In the destination
system, the Remote - Intercom
Priority Handling of priorities
Audio compression method with which the codec handles the actual connection.
Codec
The options are: µLaw (default), ADPCM (7kHz) and aLaw
AllCall No. ID of the connection
Own/Analog Selects the type of call station (ProCom or analog call stations).
Input/call station (Setting Own)
Address and port of the module to which the call station is connected and the line
Address, Port, Line
(key) that is used. (4NSA)
Input/call station (Setting Analog)
Address and port of the module to which the AF line of the call station is connected.
Address AF, Port
(4NPA)
Address 24LI, Port, Address and port of the module to which the control line of the call station is
Line connected. (24LI)
Transmission line AF
Address and port of the module to which the long-distance line for the transmission
Address, Port
of AF is connected.
Transmission line controlling
Address and port of the module to which the long-distance line for control
Address, Port
transmission is connected.
Busy line Line for transferral of the Busy status.
AllCall-Line
AllCall line
Destination of one or more programs
The line is switched on if the program is activated. For example, relays can be
Special line
switched or keys can be illuminated.
Flag (NAND) [IN] The program can be turned off by this flag or switching on can be prevented.
Flag (OR) [IN] The program can be switched on by this flag. AF channels can be taken over.
[OUT] The flag is switched on if the program is activated. This enables further
Flag (OUT) 1/2
programs to be activated for adaptation to specific requirements.
02/2018 • V.1.0 • L. Wolle
© 2017 ProCom
AllCall program without, however, the option of using the
(IC Intercom, IC Group, PA Public
program can react by means of its AllCall-Line.
(see Section
®
Professional Communication & Service GmbH • Technical changes reserved.
address, ZZ connection).
9.1)
Remote - Intercom in a remote system.
(see Section 9.1)
94/131
