User Guide
DVS-21

8.4 PCS (PC call station)

The connection of one or more PCS is at the Ethernet connector of the module LCPU. The setting of a
PCS as a call station is for the documentation at this time.
Unique number of the device
Station number The number belongs to the pool of the call station numbers in the system and it
must be unique.
Module address, Port Address and port of the module at which the PCS is connected. (LCPU)
Labeling for the call station
Name
The button Get adopts a noted description from Address description.

8.5 Measuring mic

It is necessary to register a Measuring mic as a call station so that the monitoring of the fuses of the
module MI4M is activated by the CPU.
Unique number of the device
Station number
The number belongs to the pool of the call station numbers in the system and it
must be unique.
Module address, Port Address and set of the module at which the Measuring mic is connected. (MI4M)
Labeling for the Measuring mic
Name
The button Get adopts a noted description from Address description.

8.6 Separate amplifier

Spatially separated analog amplifiers can be controlled by using the Separate amplifier function. Control
takes place by means of the
The UZ-ELA-Module enables remote PA.
A 2W-Amplifier is integrated.
External PA-Amplifiers can be connected. By feeding the loudspeaker line back to the 100V-input, it is
possible to monitor the loudspeaker line.
UZ-ELA = Control sub-center for loudspeaker system (German derivation "UnterZentrale für
Elektronische LautsprecherAnlage")
Configuration of the Separate amplifier device takes place in the
Programming takes place by means of the

Settings

Amplifier No. Unique number of the amplifier in the system
Address and port of the module to which the RS485 data line of the UZ-ELA module is
Address, Port
connected. (4DSS)
Subscriber
ID for addressing the module
No. (see Activated amplifier in Program
Volume Volume/Level of the amplifier
System call Integration in a system AllCall. (see AllCall)
Online level Level is transferred to the amplifier
02/2018 • V.1.0 • L. Wolle
© 2017 ProCom
4DSS (RS485) module and UZ-ELA modules connected to it.
PA Public address
PA Public
®
Professional Communication & Service GmbH • Technical changes reserved.
Call stations and devices
program.
address)
dialog.
73/131
