DVS-21
7.19 4DAE
Passive module for manual attenuation of 4 loudspeaker lines. This module acts within the programming
as a placeholder for documentation purposes.
No configuration required!
Display and control elements:
Switches
Rotary control switch for appropriate damping
Backplane connectors:
IN a/b
Input, from the amplifier
LK1 a/b Output 1
LK2 a/b Output 2
LK3 a/b Output 3
LK4 a/b Output 4
02/2018 • V.1.0 • L. Wolle
© 2017 ProCom
®
Professional Communication & Service GmbH • Technical changes reserved.
