Air Techniques ProVecta 3D Prime Installation Instructions Manual page 13

Detector Pano/CBCT
Frame rate
Greyscale
Acquisition
mode
Panoramic
FDD: distance from focal spot to detector
FOD: distance from focal spot to object
ODD: distance from object to detector (ODD = FDD - FOD)
Image capture scale = FDD/FOD
Electromagnetic compatibility (EMC)
Interference emission measurements
High-frequency emissions in accordance with CISPR11
Interference voltage at the power supply connection
CISPR11:2009+A1:2010
Electromagnetic interference radiation
CISPR11:2009+A1:2010
Emission of harmonics
IEC61000-3-2:2005+A1:2008+A2:2009
Voltage changes, voltage fluctuations, and emission of
flicker
IEC61000-3-3:2013
Electromagnetic compatibility (EMC)
Interference immunity measurements on cover
Immunity to interference by discharge of static electricity
IEC61000-4-2:2008
± 8 kV contact
± 2 kV, ± 4 kV, ± 8 kV, ± 15 kV air
Immunity to interference by high-frequency electromag-
netic fields
IEC61000-4-3:2006+A1:2007+A2:2010
3 V/m
80 MHz - 27 GHz
80 % AM at 1 kHz
Immunity to interference by near fields of wireless HF
communication devices
IEC61000-4-3:2006+A1:2007+A2:2010
See Table on immunity to interference table by near
fields of wireless HF communication devices
2210200497L41 1812V002
FDD FOD
mm mm
in in
600 4777
2362 1881
107 (2x2 binning)
fps 308 (4x4 binning)
bit
ODD
Image capture scale
mm
(magnification factor)
in
1223
481
Product description
535
14
126
Group 1
Class A
Conforms
Conforms
Conforms
Conforms
Conforms
Conforms
Conforms
EN
US
11
