6. Rotate the potentiometer on X-NUCLEO-IHM16M1 to regulate the motor speed.
1. To supply the NUCLEO-G431RB from the USB, the jumper JP5 must be connected between Pin 1 and Pin 2. For further
details on Nucleo settings refer to [3].
2. Supply voltage must be off before changing the control mode.
4.3

Hardware settings

Table 3 shows the jumper configuration on the X-NUCLEO-IHM16M1 board as shown in
the jumper selection, it is possible to choose the 1-shunt or 3-shunt current-sensing mode, the Hall encoder with
pull-up, or the external supply for the NUCLEO-G431RB board.
Jumper
J5
J6
J2
J3
JP4 and JP7
1. JP4 and JP7 must have both the same configuration: both left open for 3-shunt configuration, both closed for 1- shunt
configuration. On the silkscreen, the correct position for 3- or 1-shunt is indicated together with the default position.
Table 4 shows the main connectors on the X-NUCLEO-IHM16M1 board.
Screw terminal
J4
CN1
The X-NUCLEO-IHM16M1 is stacked on ST morpho connectors, male pin headers (CN7 and CN10) accessible
on both sides of the board. They can be used to connect this power board to the NUCLEO-G431RB board. All
signals and power pins for the MCU are available on the ST morpho connectors. For further details refer to the
"ST morpho connectors" section in [3].
Part reference
CN7, CN10
CN5, CN6, CN9, CN8
U1
U2
J4
J5, J6
SPEED
CN1
UM2538 - Rev 1
Selection of the FOC control algorithm.
Selection of the FOC control algorithm.
Selection of the HW current limiter threshold (disabled in 3-shunt configuration by
default).
Selection of fixed or adjustable current limiter threshold (fixed by default).
(1) Selection of 1-shunt or 3-shunt configuration (3-shunt by default).
Table 4.
Motor power supply input (7 to 45 Vdc)
3-phase motor connector (U,V,W) and Motor Power Supply input (when J4 is not used)
Table 5.
ST morpho connector
Arduino Uno connector
STSPIN830 driver
TSV994IPT op. amp.
Power-supply jack connector
Jumpers for FOC use
Potentiometer
Motor- and power-supply connector
Table 3. Jumper settings
Permitted configuration
Screw terminal table
Function
Connector description
Description
UM2538
Hardware settings
Figure 6. According to
Default
condition
CLOSED
CLOSED
[2-3]
CLOSED
[1-2]
CLOSED
OPEN
