❻ Check if the UV LED on the light board is fully illuminated when printed
❼ The lifting distance is too large
, and the position is misplaced when moving up and down for a long distance.
❽
Open the print file with SparkStudio and check for any problems with the sliced graphics.
©Why is a cuboid block that is the size of the screen printed on the printing platform
after printing is finished, or not printed anything?
❶ If the LCD screen is damaged or the contact is poor
cable and try to connect again. If it cannot be solved
❷ Check that the lamp bead on the lamp board is lit normally when printed.
❸ Open the print file with
SparkStudio and check for any problems with the sliced graphics.
❹ The copper nut mounting screw is too tight
adjusted to make the screw move smoothly.
©Why is the LCD screen not working?
❶ The resin drop into the LCD screen and damage the LCD screen.
❷ The residual resin residue on the tank or platform crushes the LCD screen during printing.
❸ The connection cable inside the LCD screen is loose during transportation.
❹ Check the FEP film in the tank
and whether there is any obstruction or resin residue on the LCD screen.
,
©Why does the bottom of the model swell?
In order to make the model stick to the bottom layer of the platform
normal layer , and the long under layer exposure time will cause the resin around the bottom layer expand
lift the model a distance and then add the bottom support.
©The aluminum plate of the printing platform has been scratched by the tool after
repeated use,can it be used?
Slight scratches have little effect on the model and it can be used continuously
plane , the stronger the adhesion.
104
©How to improve the printing speed?
and if the brightness is different.
,
, it will be completely transparent. Check the LCD screen
, replace the new LCD screen.
, the screw is stuck , and the copper nut mounting screw should be
, the bottom exposure time is longer than the
, and the rougher the metal
❶ Use a resin that cures faster.
❷ Use a larger layer thickness to save printing time.
❸ Increase the speed of descent and the speed of lifting as appropriate.
©Why is the support broken during the printing process?
❶ The layer exposure time is not enough
❷ If the support is too thin
, a thicker support should be used.
❸ The surrounding support is not dense enough,need to add more dense support.
❹ Check the FEP film up and down
❺ The lifting speed is too high and damaged the support
❻ The Z-axis motion is not smooth. Correct the Z-axis and add some grease.
❼ If the hardness of the resin is too low
©Why is the cross section of the model deformed?
❶ Because the exposure time is too long or insufficient
❷ The resin selected is not in the specified curing band.
❸ Some points are are not adding support and the model part is sunken and deformed.
❹ The platform handle is not tightened when printing.
❺ The tank is not installed well.
❻ Check the FEP film up and down
❼ If the hardness of the resin is too low
, you can
©Why is the height of the printed model incorrect?
❶ The platform is not leveled.
❷ Z-axis stuck
, the Z-axis should be corrected and grease added.
❸ The platform handle is not tightened when printing.
❹ The underlying exposure time is too long and the bottom layer is inflated.
❺ Because the exposure time is too long or insufficient
, the layer exposure time should be increased appropriately.
, whether there is any obstruction or resin residue on the LCD screen.
, the lifting speed should be reduced appropriately.
, a resin with a higher hardness should be used.
, the exposure time should be adjusted appropriately.
, whether there is any obstruction or resin residue on the LCD screen.
, a resin with a higher hardness should be used.
, the exposure time should be adjusted appropriately.
