Take out the LCD screen
and pull out the LCD cable
from the gap on the left side
of the working panel.
＊ Notice:
❶ D o n o t d a m a g e o r s t a i n t h e
tempered glass behind the LCD screen.
❷ Do not remove the tempered glass
behind the LCD screen.
60
LCD screen
LCD screen cable
Extend the cable of the new LCD
screen into the interior along the
left side gap of the working panel
and install the new LCD screen in
the correct position.
＊ Notice:
❶ Before installing,please remove
the protective film on both sides of the
new LCD.
❷ Do not damage or stain the LCD
screen and the tempered glass behind
the LCD screen during installation.
LCD screen
LCD screen cable
