Insert 12 M3 short screws into the position where the hole was
previously poked.
Lower layer of the tank
Align the lower layer of the tank with the rubber washer according
50
to the screw holes position.
M3 short screw
FEP film
FEP film
M3 short screw
Rubber washer
Small hex wrench
Lower layer of the tank
Middle layer of the tank
Align the lower layer of the tank and the middle layer of the tank
according to the screw holes. Use a small hex wrench to tighten the
screws clockwise to clamp the FEP film and rubber washer.
FEP film
Rubber washer
M3 short screw
51
