❸ Please use SDHC (Secure Digital High Capacity) with a maximum capacity lower than 32GB.
Adapter:
Used to convert 110V-240V AC to 24V DC to provide power to the printer.
DC socket: Located at the right rear of the printer,is the power socket to connect the printer and the
adapter.
Notice:
❶ Do not use a non-original power adapter to avoid danger.
❷ Please plug in the print DC socket before powering on the adapter. Do not plug in the DC socket after the
adapter is powered.
Light board: Provide UV light to cure the liquid resin in the tank.
Notice:
❶ Do not look directly at the UV light emitting from the light board. Wear goggles if do it.
❷ Please ensure that the fan works normally when the light board is working to avoid damage to the
machine caused by excessive temperature.
Shading tape: Used to block the unrequired UV light around the LCD screen.
LCD screen: Used to display the section pattern of the printed model and cooperate with the UV light to cure the
resin.
Notice:
❶ The LCD screen is extremely fragile,please be careful.
❷ If the tank leaks out and causes the resin to flow out and cured on the LCD screen,please carefully remove the
cured resin residue before the next printing.
❸ Make sure that there are no resin residues on the LCD screen to block UV light.
❹ If the print failed,please clean the residual resin in the tank and aluminum plate in time to avoid crushing the
LCD screen when printing next time.
❺ Make sure the printing platform is properly leveled when printing,so as to avoid damage to the LCD screen.
❻ Please ensure that the FEP film is close to the LCD screen to avoid affecting the print quality.
❼ Make sure that the black tape completely block the unrequired UV light around the LCD screen.
20
Screw motor:
Used to drive the lifting cantilever move up and down.
Copper nut:
For working with screw motors.
Guide rail:
For linear motion guidance.
lifting cantilever:
Motor and guide rail control its up and down during printing.
Notice:
❶ Do not block the rotation of the screw motor.
❷ Do not over-tighten the mounting screws of the copper nut.
❸ Do not drop resin and other debris on the guide rail and the screw that interfere with its work.
❹ Please add grease to the screw,copper nut and guide rail in time to avoid excessive abrasion.
❺ Do not drop the resin on the baffle. If it is accidentally dropped,please clean it in time.
Photosensitive resin: Liquid light curing resin for printer use.
Notice:
❶ Do not touch the skin directly with the resin. Wear gloves when handling. If skin contact occurs,wash
it with soapy water. If you feel unwell,please consult a doctor.
❷ The resin remaining after printing,if it would not be used for a long time,please keep it in cool and dark place.
❸ Shake the resin evenly before use.
❹ Do not eat the printed model and the resin used for printing.
❺ Keep the resin out of reach of children and pets.
❻ Do not drop the resin on any parts other than the tank and aluminum plate.If it is dropped,please clean it in
time.
❼ Use of third-party color paste or other dyes may result in printing failure or damage to the printer.
Working panel: Panel for mounting components such as LCD screens and tank.
Hexagonal wrench: Big hex wrench and small hex wrench for hex screws.
Trigger piece:
Used to trigger photoelectric switch.
Photoelectric switch:
Used to determine if the platform has reached the lowest point.
Notice:
❶ Do not block the photoelectric switch,otherwise the photoelectric switch will not be triggered.
