❷ When leveling,please ensure that the trigger piece is inserted into the photoelectric switch groove.
❸ Do not drop the resin on the working panel and photoelectric switch.
Fan:
Cooling the control system and the light board.
Notice:
❶ Make sure that the cooling fan is working properly and avoid system failure due to excessive temperature.
❷ Please make sure not to block the air outlet and air inlet.
LCD screen FPC cable: Connecting the mainboard to the LCD screen.
Alcohol: A cleaning agent used to clean printed models.
Note:
1.Please use alcohol with a concentration higher than 95%.
2.Do not soak the model in alcohol for too long.
3.Please use alcohol carefully to avoid safety risks.
UV curing lamp: used to solidify the newly printed model so that it is completely solidified.
Note:
1.Please use a curing lamp with a band of 395-420nm and a power of more than 10W.
2.When curing the model with curing lamp,the model can be placed in glycerin to prevent the deformation of the
model due to temperature and other factors in the curing process.
3.Too long post-curing time will lead to shrinkage and yellowing of the model,and too short post-curing time will
lead to the incomplete curing model of the model is soft.
22

Check before printing

❶ Keep the power connection stable.
❷ Knob rotates smoothly and presses smoothly.
❸ Z-axis movement is smooth and unobstructed.
❹ There is no resin residue on the aluminum plate of the printing platform.
❺ The handle on the print platform has been tightened.
❻ The print platform has been correctly leveled.
❼ The tank is installed correctly,and the FEP film at the bottom of the tank is close to the LCD screen.
❽ No resin residue in the tank and on the FEP film.
❾ No residual resin on the outer wall of the tank,the bottom of the tank,the LCD screen and the working
panel.
❿ The resin poured into the tank is less than 240ml. If the model is large,the resin can be added during
the printing process.
⓫ Printed model files have no fault and are not damaged.
⓬ Ensure the model's the position of the long-span cantileve,the lowest point of the layer and the position
that needs to be strengthened,add with the right size of support and the right amount of support,and the
right bottom valve.
⓭ The slice parameters such as the layer thickness,exposure time,and lifting speed of the print file are set
correctly.
⓮ The slice file is completely saved in the SD card,the bottom surface of the model is completely attached
to the lowest point of the printer,and there is no fault on the print model file
⓯ If you use the knob to control the printer to print,you need to name the print file as"print.wow"(for
SparkMaker version)or "print.fhd" (for SparkMaker FHD
⓰ The SD card is a C10 high-speed card with a capacity lower than 32GB . The file system format is
FAT32 . The SD card is completely unlocked by hardware. The metal contacts are intact and free of stains.
⓱ When the card slot is inserted,the SD card metal contact point is inserted face up into the machine card
slot and is in fully contact with it.
version),and save it to the SD card.
