Use the big hex wrench to
adjust the two positioning
ro u n d h e a d s c r e w s f o r
mounting the Z axis and the
three round head screws on
the bottom of the printer.
＊ Notice:
After adjusting the installation,the
screws should be properly tightened.
Big hex wrench
Round head screw
Washer
82
Big hex wrench
Screw
Round head screw
K e e p t h e t w o c o p p e r n u t
mounting holes at the top of
the cantilever on the same
horizontal line as the center of
the screw.
＊ Notice:
Move the cantilever to the top and adjust.
Copper nut mounting hole
Screw
83
