Power Ratings and Product Selection

VSD Series II Drives—208–230 Volt

NEMA Type 1/IP21 or NEMA Type 12/IP54

Drive Rated Current and hp
Drive Rating
FS Low Overload
Frame Full Load
Size Amps at 40°C
FS4 3.7
4.8
6.6
8
11
12.5
FS5 18
24
31
FS6 48
62
FS7 75
88
105
FS8 140
170
205
FS9 261
310
Notes
For sizing reference, full-load motor running currents—UL508C.
If SA-Bus is required, replace -00000 with -S0000.
230V Drive
60 Hz Input
Horsepower Amps
0.75 3.2
1 4.3
1.5 6
2 7.2
3 9.7
4 10.9
5 16.1
7.5 21.7
10 27.7
15 43.8
20 57
25 69
30 82.1
40 99
50 133
60 163
75 198
100 256
125 303
De-Rated
NEC Motor Low Overload
60 Hz Full Load
230V Amps Amps at 50°C
3.2 2.6
4.2 3.7
6 4.6
6.8 6.6
9.6 8
N/A 9
15.2 12.5
22 18
28 25
42 31
54 48
68 62
80 75
104 88
130 114
154 140
192 170
248 211
N/A 251
VSD Series II LIT-12011772—October 2012 www.johnsoncontrols.com
VSD Series II Overview
Assigned
Motor Ratings x = Can Be:
Open Drive 1 = N1 = IP21
kW 2 = N12 = IP54
230V
50 Hz Catalog Number
0.55 VS3D72x0B-00000
0.75 VS4D82x0B-00000
1.1 VS6D62x0B-00000
1.5 VS8D02x0B-00000
2.2 VS0112x0B-00000
3 VS0122x0B-00000
4 VS0182x0B-00000
5.5 VS0242x0B-00000
7.5 VS0312x0B-00000
11 VS0482x0B-00000
15 VS0622x0B-00000
18.5 VS0752x0B-00000
22 VS0882x0B-00000
30 VS1052x0B-00000
37 VS1402x0B-00000
45 VS1702x0B-00000
55 VS2052x0B-00000
75 VS2612x0B-00000
90 VS3102x0B-00000
17
