Appendix A
VSD Series II Technical Data, continued
Attribute Description
Ambient conditions, Vibration:
continued
•
•
Shock:
•
•
Enclosure class
EMC (at default settings) Immunity
Emissions
Noise level Average noise level (cooling fan)
sound power level in dB(A)
Safety —
Protections Overvoltage trip limit
Undervoltage trip limit
Earth fault protection
Mains supervision
Motor phase supervision
Overcurrent protection
Unit overtemperature protection
Motor overload protection
Motor stall protection
Motor underload protection
Short-circuit protection of 24V
and 10V reference voltages
40 VSD Series II LIT-12011772—October 2012 www.johnsoncontrols.com
EN61800-5-1
EN60668-2-6
EN61800-5-1
EN60068-2-27
Specification
5–150 Hz
Displacement amplitude:
1 mm (peak) at 5–15.8 Hz (FS4–FS9)
Maximum acceleration amplitude:
1g at 15.8–150 Hz (FS4–FS9)
UPS drop test (for applicable UPS weights)
Storage and shipping: Maximum 15g, 11 ms (in
package)
IP21/Type 1 standard in entire kW/hp range
IP54/Type 12 option
Note: Keypad required for IP54/Type12
Fulfils EN61800-3 (2004), first and second
environment
+EMC2: EN61800-3 (2004), Category C2
The drive can be modified for IT-networks
FS4: 65 FS7: 77
FS5: 70 FS8: 86
FS5: 77 FS9: 87
EN61800-5-1 (2007), CE, cUL (see nameplate for more
detailed approvals)
240V drives: 456V
480V drives: 911V
Depends on supply voltage (0,8775*supply voltage):
Supply voltage 240V: Trip limit 211V
Supply voltage 400V: Trip limit 351V
Supply voltage 480V: Trip limit 421V
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
