Appendix A

Technical Data

VSD Series II Technical Data

Attribute Description
Mains connection Input voltage U in
Input frequency
Connection to mains
Starting delay
Motor connection Output voltage
Continuous output current
Output frequency
Frequency resolution
Control characteristics Switching frequency
(see parameter P3.1.2.1)
Frequency reference
Analog input
Panel reference
Field weakening point
Acceleration time
Deceleration time
Ambient conditions Ambient operating temperature
Storage temperature
Relative humidity
Air quality:
•
•
Altitude
Chemical vapors
Mechanical particles
Specification
208–240V, 380–480V, –10 to 10%
50–60 Hz, –5 to 10%
Once per minute or less
4s (FS4 to FS6), 6s (FS7 to FS9)
0-U in
I L : Ambient temperature maximum 40°C, up to 50°C
with derating, overload 1.1 x I L (1 min./10 min.)
0–320 Hz (standard)
0.01 Hz
1.5–10 kHz
Defaults:
FS4–6: 6 kHz (except 0012 2, 0031 2, 0062 2, 0012 4,
0031 4 and 0061 4: 4 kHz)
FS7: 4 kHz
FS8–9: 3 kHz
Automatic switching frequency derating in case of
overload.
Resolution 0.1% (10-bit), accuracy +1%
Resolution 0.01 Hz
8–320 Hz
0.1–3000 sec.
0.1–3000 sec.
I L : –10°C (no frost) to 40°C, up to 50°C with derating
–40° to 70°C
0–95% R H , non-condensing, non-corrosive
Tested according to IEC 60068-2-60 Test Ke:
Flowing mixed gas corrosion test, Method 1
(H 2 S [hydrogen sulfide] and SO 2 [sulfur dioxide])
Designed according to:
IEC 60721-3-3, unit in operation, class 3C2
IEC 60721-3-3, unit in operation, class 3S2
100% load capacity (no derating) up to 1000m
1% derating for each 100m above 1000m
Max. altitudes:
208–240V: 4500m (TN and IT systems)
380–480V: 4500m (TN and IT systems)
Voltage for I/O signals:
Up to 2000m: Allowed up to 240V
2000–4500m: Allowed up to 120V
Corner-grounding: Up to 2000m only
