Power Ratings and Product Selection

Series II Series Drives – 525-600V
NEMA Type 1/IP21 or NEMA Type 12/IP54
Drive Rated Current and hp
Drive Rating
Low Overload Full
Frame Load Amps at
Size 40°C
FR5
3.9
6.1
9
11
FR6
18
22
27
34
FR7
41
52
62
FR8
80
100
125
FR9
144
208
Drives
600V 60Hz Input
Horsepower Amps
3 4.6
5 6.8
7.5 9
10 10.5
15 19.9
20 23.3
25 27.2
30 32.8
40 45.3
50 53.8
60 62.2
75 90
100 106
125 127
150 156
200 212
www.johnsoncontrols.com
De-Rated _ Can Be:
Low Overload 1 = N1 = IP21
Full Load Amps 2 = N12 = IP54
at 50°C Catalog Number
3.3 VS3D95_0B-00000
5.2 VS6D15_0B-00000
7.7 VS9D05_0B-00000
9.4 VS0115_0B-00000
15 VS0185_0B-00000
18 VS0225_0B-00000
23 VS0275_0B-00000
28 VS0345_0B-00000
34 VS0415_0B-00000
44 VS0525_0B-00000
52 VS0625_0B-00000
68 VS0805_0B-00000
85 VS1005_0B-00000
106 VS1255_0B-00000
122 VS1445_0B-00000
176 VS2085_0B-00000
LIT-12012316
Effective May 2017
11
