Control Board

The main VSD Series II VSD consists of a main control board, control I/O connections block
and two slots for extra option boards.

VSD Series II Variable Speed Drive

Battery
(Standard)
RJ45
EtherNet
BACnet IP
Modbus TCP
Slot D
Option Board
21 22 23
Slot B
R01
NC
12 13 14 15 16 17 18 19 30 A
Control
24 Vdc
OUT
I/O
1
+10
Vdc
Line
Removable
EMC Filter Clip
L L
1 2
Line Ground
Clamp Location
Grounding
Strap Location
Line Side
Control Wiring
All control I/O wiring must be segregated from line (mains) and motor cabling
●
Control wiring shall be shielded twisted pairs. To meet EMC levels required by ENG1800-3 (2004).
●
Control wiring must be Type 4 cable
Run 120 Vac and +24 Vdc control I/O in separate conduit
●
Control I/O terminals must be tightened to 4.5 lb (0.5 Nm)
●
CURRENT
CURRENT
CURRENT
Optional NEMA 12 Fan Location
24 25 26 32 33
R01 R01 R02 R02 R02 R03 R03
COM NO NC COM NO COM NO
B
COM A01 A02
24 Vdc RS-485 RS-485
GND DI4 DI5 DI6
D11-6 + – IN DATA– DATA+
2 3 4 5 6 7 8 9 10 11
COM
24 Vdc
AI1+ AI1– AI2+ AI2– GND DI1 DI2 DI3
OUT DI1-6
Motor
L R+ R– U/T V/T W/T
3 1 2 3
Motor
Keypad
(U.S. version shown)
Analog
Switch Control
VOLTAGE AO1
VOLTAGE AI2
VOLTAGE AI1
Slot E
Option Board
ON ON
DGND and RS-485
Termination
OFF OFF
RS-485 Modbus RTU
BACnet N2, FLN
Removable
EMC Filter Clip
Motor Ground
Clamp Location
Grounding
Strap Location
VSD Series II LIT-12011772—October 2012 www.johnsoncontrols.com
