International Cable and Fuse Sizes 380–480 Vac Ratings
Amp
Frame Suffix
FS4 3D4
4D8
5D6
8D0
9D6
012
FS5 016
023
031
FS6 038
046
061
FS7 072
087
105
FS8 140
170
205
FS9 261
310
Note:
1. If power cubes are used, a UL recognized Type T fuse is recommended.
2. Based on maximum environment of 104°F (40°C).
3. If bypass is used, a UL recognized Type T fuse is recommended
VSD VSD
I(L) I(L) [kW]
Amps Amps 400V
at at at
40° C 50° C 50 Hz
3.4 2.6 1.1
4.8 3.4 1.5
5.6 4.3 2.2
8.0 5.6 3.0
9.6 8 4
16 12 7.5
23 16 11
31 23 15
38 31 18.5
46 38 22
61 46 30
72 61 37
87 72 45
105 87 55
140 105 75
170 140 90
205 170 110
261 205 132
310 251 160
3.4 2.6 1.1
Mains and
Fuse Motor
Rating Cable
(gG/gL) Cu (mm
6 3*1.5+1.5
6 3*1.5+1.5
10 3*1.5+1.53
16 3*2.5+2.5
16 3*2.5+2.5
16 3*2.5+2.5
20 3*6+6
25 3*6+6
32 3*10+10
40 3*10+10
50 3*16+16
63 3*25+16
80 3*35+16
100 3*35+16
125 3*50+25
160 3*70+35
200 3*95+50
250 3*120+70
315 3*185+95
350 2*3*95+50
VSD Series II LIT-12011772—October 2012 www.johnsoncontrols.com
Terminal
Cable Size
Main Earth
Terminal Terminal
2 2
) Cu (mm ) Cu (mm
1–6 solid or 1–6
1–4 stranded
1–6 solid or 1–6
1–4 stranded
1–6 solid or 1–6
1–4 stranded
1–6 solid or 1–6
1–4 stranded
1–6 solid or 1–6
1–4 stranded
1–6 solid or 1–6
1–4 stranded
1–10 1–10
1–10 1–10
1–10 1–10
2.5–50 2.5–35
2.5–50 2.5–35
2.5–50 2.5–35
6–70 6–70
6–70 6–70
6–70 6–70
35–185 6–70
35–185 6–70
35–185 6–70
35–185 6–95
35–185 6–95
Appendix B
