VSD Series II Overview

Catalog Number Selection

VSD Series II Open Drives

VS = VSD Series
Open Style Amps/Rating
208–240 Volts 3PH 380–480 Volts 3PH
3D7 = 3.7 Amp (3/4 Hp, 0.75 kW)
4D8 = 4.8 Amp (1 Hp, 1.1 kW)
6D6 = 6.6 Amp (1.5 Hp, 1.1 kW)
8D0 = 8 Amp (2 Hp, 1.5 kW)
011 = 11 Amp (3 Hp, 2.2 kW)
012 = 12 Amp (4 Hp, 3 kW)
018 = 18 Amp (5 Hp, 4 kW)
024 = 24 Amp (7.5 Hp, 5.5 kW)
031 = 31 Amp (10 Hp, 7.5 kW)
048 = 48 Amp (15 Hp, 11 kW)
062 = 62 Amp (20 Hp, 15 kW)
075 = 75 Amp (25 Hp, 18.5 kW)
088 = 88 Amp (30 Hp, 22 kW)
105 = 105 Amp (40 Hp, 30 kW)
140 = 140 Amp (50 Hp, 37 kW)
170 = 170 Amp (60 Hp, 45 kW)
205 = 205 Amp (75 Hp, 55 kW)
261 = 261 Amp (100 Hp, 75 kW)
310 = 310 Amp (125 Hp, 90 kW)
Note
Solutions pending. Check with your Johnson Controls representative for availability.
16 VSD Series II LIT-12011772—October 2012 www.johnsoncontrols.com
VS 3D4 4 1 1 B - S 0000
310
Base Product
3D4 = 3.4 Amp (1.5 Hp, 1.1 kW)
4D8 = 4.8 Amp (2 Hp, 1.5 kW)
5D6 = 5.6 Amp (3 Hp, 2.2 kW)
8D0 = 8 Amp (4 Hp, 3 kW)
9D6 = 9.6 Amp (5 Hp, 4 kW)
012 = 12 Amp (7.5 Hp, 5.5 kW)
016 = 16 Amp (10 Hp, 7.5 kW)
023 = 23 Amp (15 Hp, 11 kW)
031 = 31 Amp (20 Hp, 15 kW)
038 = 38 Amp (25 Hp, 18.5 kW)
046 = 46 Amp (30 Hp, 22 kW)
061 = 61 Amp (40 Hp, 30 kW)
072 = 72 Amp (50 Hp, 37 kW)
087 = 87 Amp (60 Hp, 45 kW)
105 = 105 Amp (75 Hp, 55 kW)
140 = 140 Amp (100 Hp, 75 kW)
170 = 170 Amp (125 Hp, 90 kW)
205 = 205 Amp (150 Hp, 110 kW)
261 = 261 Amp (200 Hp, 132 kW)
310 = 310 Amp (250 Hp, 160 kW)
Voltage
1 = 208V
2 = 230V
4 = 480V
5 = 575V
Enclosure Rating
1 = Nema-UL Type 1 (IP21)
2 = Nema-UL Type 12 (IP54)
4 = Flange Mtd for FS8 and
FS9 (IP00)
Drive Style
0 = Open
Revision
B = Rev 2 (Americas)
D = Rev 2 (Canada)
Options (Ordered Separately)
VS-XMX-K9-FS4-5 = Aux Contacts
Qty 2 (FS4-5 Bypass and Drive Output Contactors)
VS-XMX-K9-FS6-9 = Aux Contacts
Qty 2 (FS6-9 Bypass and Drive Output Contactors)
Extended I/O Options in Slot D and E
(Ordered Separately)
VS-XMX-B1 = 6 DI or DO, 1 ext +24 Vdc/EXT +24 Vdc
Programmable
VS-XMX-B2 = 1 RO (NC/NO), 1 RO (NO), 1 Thermistor
VS-XMX-B4 = 1 AI (mA isolated), 2 AO (mA isolated)
VS-XMX-B5 = Card-3 Relay Dry Contact
VS-XMX-B9 = 1 RO (NO), 5 DI 42–240 Vac Input
VS-XMX-BF = Expander IO—1*AO, 1*DO, 1*RO
VS-XMX-CS = SA Bus (JC-VSD only)
VS-XMX-C4 = Lon Works Comm Card
I/O Options in Slot B
(Ordered Separately)
VS-XMX-F1 = 3 relay (spare/replacement part only—
not option w/standard VSD)
VS-XMX-F2 = 2 relay and 1 Thermistor- not available
with L3/L4 Pilot light option replaces standard
Relay1 pcb in Slot B and Fault Relay function
RS-485 Optional Comms Slot D and E
0 = STD BACnet/Modbus
S = SA Bus, CS card (added to JC-VSD)
L = Lon Works, C4 Card (Open Only)
