Step 3—Menu Navigation
Step 3—Menu Navigation
Menu Structure
Table 4. Keypad Menu
Item Description
Monitor M1—Basic
M2—IO Status
M3—Optional Boards
M4—Energy savings
M5—FB Monitor Menu
M6—PID Monitor
M7—Timer/Interval Control
M8—User Defined Output
M9—MWH Monitor
M10—Multi-Monitoring
Parameters P1—Basic Parameter
P2—Inputs
P3—Outputs
P4—Drive Control
P5—Motor Control
P6—Protections
P7—PID Controller 1
P8—PID Controller 2
P9—Fire Mode
P10—Bypass
P11—Real Time Clock
P12—Communication
P13—System
Note: Will vary depending on application selected.
6 Variable Speed Drives Series III LIT-12012996—April 2018 www.johnsoncontrols.com
Item Description
Fault F1—Active Fault
F2—History Fault
F3—Fault Log
Option Boards B1—Slot A
B2—Slot B
Favorite
Operate Mode O1—Output Frequency
O2—Freq Reference
O3—Motor Speed
O4—Motor Current
O5—Motor Torque
O6—Motor Power
O7—Motor Voltage
O8—DC-link Voltage
O9—Unit Temperature
O10—Motor Temperature
R11—Keypad Reference
R12—PID1 Keypad Set Point 1
R13—PID1 Keypad Set Point 2
Startup Wizard S—Startup Wizard
