Table 32. Drive—P6.2
Code Parameter
P6.2.1 2 Line Start Lockout
P6.2.2 2 Fault Reset Start
P6.2.3 4mA Input Fault
1 2
P6.2.4 4mA Fault Frequency
1 2
P6.2.5 External Fault
1 2
P6.2.6 1 2 Input Phase Fault
P6.2.7 Uvolt Fault Response
1 2
P6.2.8 1 2 Unit Under Temp Prot
P6.2.9 RTC Fault
1 2
P6.2.10 1 2 Replace Battery Fault
Response
P6.2.11 1 2 Replace Fan Fault Response
P6.2.12 Cold Weather Mode
2
P6.2.13 2 Cold Weather Volt. Level
P6.2.14 Cold Weather Time Out
2
P6.2.15 Cold Weather Password
P6.2.16 Under Temp Fault Override
P6.2.17 2 STO Fault Response
Table 33. Communication—P6.3
Code Parameter
P6.3.1 1 2 Fieldbus Fault Response
P6.3.2 1 2 OPTCard Fault Response
P6.3.3 IP Address Confliction Resp
1 2
P6.3.4 1 2 Keypad Comm Fault
Response
Notes
1
Parameter value can only be changed after the drive has stopped.
2
Parameter value will be set to be default when changing macros.
Min. Max.
0.00 See Par ID 102
0.0 20.0
0 10
Min. Max.
Variable Speed Drives Series III LIT-12012996—April 2018 www.johnsoncontrols.com
Unit Default
2
0
0
Hz 0.00
2
2
2
2
1
1
1
0
% 2.0
min 3
2
Unit Default
2
2
1
2
3
Input function is Level sensed.
4
Input function is Edge sensed.
5
Input function is Edge sensed when using StartP/StopP start logic.
Step 5—Standard Parameter List
ID Note
750 0 = Disabled, No Change
1 = Enable, No Change
2 = Disabled, Changed
3 = Enable, Changed
2483 0 = Start/Stop After Fault Reset
1 = Restart After Fault Reset
306 0 = No Action
1 = Warning
2 = Warning: Previous Freq
3 = Warning: Preset Freq
4 = Fault
5 = Fault, Coast
331
307 See Par ID 308
332 See Par ID 308
330 See Par ID 308
1564 See Par ID 308
955 See Par ID 308
1256 See Par ID 308
1257 See Par ID 308
2126 See Par ID 1679
2127
2128
2129
2130 See Par ID 2118
2427 0 = No Action
1 = Warning
2 = Fault
ID Note
334 0 = No Action
1 = Warning
2 = Fault
3 = Fault, Coast
4 = Warning, Coast
335 See Par ID 308
1678 See Par ID 308
2157 See Par ID 308
29
