Appendix A—Fault and Warning Codes
Table 52. Fault Codes and Descriptions, continued
Fault
Code Fault Name
90 Drive Under Temp
91 Option Card Fault
92 External Fault 2
93 External Fault 3
103 Drive OverTemp
Warning
104 Compatibility Fault
105 Compatibility Fault
106 Compatibility Fault
107 Compatibility Fault
108 Compatibility Fault
109 Compatibility Fault
110 Compatibility Fault
111 Compatibility Fault
44 Variable Speed Drives Series III LIT-12012996—April 2018 www.johnsoncontrols.com
Default
Fault Type Fault Type
Warning/Fault
Configurable Fault
Configurable Fault
Configurable Fault
Warning
Warning
Warning
Warning
Warning
Warning
Warning
Warning
Warning
Possible Cause
• Cold weather mode is not enabled, and
unit temperature is less than -10 degree.
• Cold weather mode is enabled and Under
Temp Fault Override is not set, unit
temperature is less than -30 degree.
• Cold weather mode is enabled and Under
Temp Fault Override is not set, unit
temperature is -20~ -30 degree. The temp
<-20 degree when cold weather start
times out.
External supply on the DeviceNet
communication connector is not present.
Digital input is activated for external
fault input.
Digital input is activated for external
fault input.
Drive degree greater than
(DCI_wDriveOverTempThreshold value -10
degree) and less than
DCI_wDriveOverTempThreshold value,report
drive over temperature warning.
DSP firmware is not compatible with
MCB firmware
Keypad firmware is not compatible with
MCB firmware
IO1 card firmware is not compatible with
MCB firmware
IO2 card firmware is not compatible
with MCB firmware
IO3 card firmware is not compatible
with MCB firmware
IO4 card firmware is not compatible
with MCB firmware
IO5 card firmware is not compatible
with MCB firmware
Profibus card firmware is not compatible
with MCB firmware
Remedy
If unit temp -20 ~ -10 degree, start motor in
cold weather mode.
If unit temp <-20°, warm up unit above
-20°C for proper operation using cold
weather mode.If still < -20° when cold
weather mode times out, try higher output
voltage in cold weather mode.
Check voltage and wiring of power supply
of the DeviceNet communication.
Check digital input settings and verify input
level, could be an external device causing
fault.
Check digital input settings and verify input
level, could be an external device causing
fault.
Check the drive degree
Check the DSP firmware revision
Check the keypad firmware revision
Check the IO1 card firmware revision
Check the IO2 card firmware revision
Check the IO3 card firmware revision
Check the IO4 card firmware revision
Check the IO5 card firmware revision
Check the Profibus card firmware revision
