Step 5—Standard Parameter List
Table 45. BACnet IP—P12.4.3
Code Parameter
P12.4.3.1 1 2 BACnet IP UDP port number
P12.4.3.2 BACnet IP Foreign Device
2
P12.4.3.3 2 BACnet IP BBMD IP
P12.4.3.4 BACnet IP BBMD Port
2
P12.4.3.5 2 BACnet IP Registration
Interval
P12.4.3.6 2 BACnet IP Comm Timeout
P12.4.3.7 BACnet IP Protocol Status
P12.4.3.8 2 BACnet IP Fault Behavior
P12.4.3.9 BACnetIP Instance Number 0
1
System
Table 46. Basic Setting—P13.1
Code Parameter
P13.1.1 Language
P13.1.2 1 Application
P13.1.3 Parameter Sets
1
P13.1.4 Up To Keypad
P13.1.5 Down From Keypad
1
Notes
1
Parameter value can only be changed after the drive has stopped.
2
Parameter value will be set to be default when changing macros.
36 Variable Speed Drives Series III LIT-12012996—April 2018 www.johnsoncontrols.com
Min. Max.
0 65535
0 60000
4194302
Min. Max.
Unit Default
47808
0
0.0.0.0
47808
10
0
0
0
Unit Default
0
3
Input function is Level sensed.
4
Input function is Edge sensed.
5
Input function is Edge sensed when using StartP/StopP start logic.
ID Note
1733 47808 = BAC0
47809 = BAC1
47810 = BAC2
47811 = BAC3
47812 = BAC4
47813 = BAC5
47814 = BAC6
47815 = BAC7
47816 = BAC8
47817 = BAC9
47818 = BACA
47819 = BACB
47820 = BACC
47821 = BACD
47822 = BACE
47823 = BACF
1734 See Par ID 1679
1735
1737 See Par ID 1733
1738
1739
1740 See Par ID 599
1741 See Par ID 2516
1742
ID Note
340 0 = English
1 =
2 = Deutsch
142 0 = Basic
1 = PID
2 = Advanced
619 0 = No
1 = Reload Defaults
2 = Reload Set 1
3 = Reload Set 2
4 = Store Set 1
5 = Store Set 2
6 = Reset
7 = Reload Defaults VM
620 See Par ID 2118
621 0 = No
1 = All Parameters
2 = All, No Motor
3 = App Parameters
